Corning® 10 x 10 Inch Top PC-620D Stirring Hot Plate with Digital Displays, 230V/50Hz

Corning digital hot plates, stirrers, and stirring hot plates are made with the same durability and quality Corning has been putting into Pyroceram® top products since 1964. All models include a Pyroceram top and a two-year warranty.

• Twin display stirring hot plate shows both temperature and stirring speed on separate digital displays to ensure accuracy. Accuracy within ±2°C and stirring speeds at ±5% of the speed setting you choose
• Digital displays indicate when set temperature and stirring speeds are reached
• Safety indicators – power button and hot top indicators warn if unit is plugged in or is too hot to touch
• Angled front panel and large knobs minimize damage from spills
• PC-400D/410D/420D top plate size: 5 x 7 in. (12.7 x 17.8 cm)
• PC-600D/610D/620D top plate size: 10 x 10 in. (25.4 x 25.4 cm)

(This is the suggested replacement for 6796-620)

The Corning® PC-620D stirring hot plate has a 10 x 10 (25.4 x 25.4cm) Pyroceram® top and digital temperature and stirring speed displays. It is designed to operate on 230V/50Hz with either the BS 1363A or CEE7-7 plug (both included) for use in parts of Europe, Asia, Africa, Australia and other areas with similar electrical requirements. A Model PC-420D is shown to the left with optional temperature controller and support rod (Cat. No. 440129).

2 year warranty

This product is CE marked and UL/cUL approved.

For information on repairs or replacement parts, please contact Corning customer Service or your Authorized Repair Facilities.

Performance Features:

Microprocessor maintains consistent and repeatable temperature settings from 5°C (if ambient temperature is 0°C or lower) up to 550°C.

Digital LED temperature display is adjustable in 5°C increments and blinks until set temperature is reached.

Optional external temperature controller (Cat. No. 6795PR) truly controls temperature inside the vessel.

Exclusive closed-loop stirring control monitors and regulates the stirring speed from 60-1150 RPM for aqueous, viscous, or semi-solid solutions.

Stronger, larger magnet improves stir bar coupling combined with automatic ramp up speed adjustment minimizes decoupling.

"
